Mirror Etched Stainless Steel Home Lift Elevator Small Cabin Decoration

  • 1
  • 2

Brand Name : SUNNY

Model Number : Home Lift

Certification : CE,ISO9001

Place of Origin : China

MOQ : 1set

Price : $7000~12000

Payment Terms : L/C, T/T, Western Union

Supply Ability : 500 Set/ Year

Delivery Time : 15~30 days

Packaging Details : container

Name : Home Lift

Load : 450~1600kg

Speed : 1.0~3.0m/S

Power Supply : 3 Phase, 380V, 50Hz

Application : Home Usage

Elevator type : Passenger Elevators

Material : Mirror etched stainless steel

Type : Home Lift

Product : Home Lift

Contact Now

Home Elevator Home Lift Elevator Small Cabin Design / Elevator Cabin Decoration



Home Passenger Elevator

Specifications:

Passenger elevators descriptions with small machine room:

Small Machine Room Available Specifications

Persons Rated Capacity(KG)

Rated Speed

(m/s)

Inner Dimension

(mm)

 Size of Door(mm) Hoistway Size(mm) Machine Room Dimension
6 450 1.0-1.75 1300×950 700×2100 1800×1650 1800×2000×2500
8 630 1.0-1.75 1400×1100 800×2100 2000×1750 2000×2000×2500
10 800 1.0-3.0 1400×1350 800×2100 2000×2000 2000×2000×2500
12 900 1.0-3.0 1400×1500 900×2100 2000×2200 2000×2200×2500
13 1000 1.0-3.0 1600×1400 900×2100 2200×2100 2200×2100×2500
15 1150 1.0-3.0 1600×1600 900×2100 2200×2300 2200×2300×2500
16 1250 1.0-3.0 1750×1600 1000×2100 2350×2300 2350×2300×2500
18 1350 1.0-3.0 1800×1650 1000×2100 2400×2400 2400×2400×2500
21 1600 1.0-3.0 1950×1750 1100×2100 2900×2300 2900×2300×2500





Mirror Etched Stainless Steel Home Lift Elevator Small Cabin Decoration



Mirror Etched Stainless Steel Home Lift Elevator Small Cabin Decoration



Mirror Etched Stainless Steel Home Lift Elevator Small Cabin Decoration



Mirror Etched Stainless Steel Home Lift Elevator Small Cabin Decoration



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.


Product Tags:

Cabin Decoration Home Elevator



Mirror Etched Stainless Steel Home Lift



3.0m/S Residential Home Lift
