1600kg 1.0m/S Low Noise Etched SS Machine Room Less Elevator for Building

SHANGHAI SUNNY ELEVATOR CO.,LTD
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

1600kg 1.0m/S Low Noise Etched SS Machine Room Less Elevator for Building

  • 1
  • 2

Brand Name : SUNNY

Model Number : Machine Roomless Elevator

Certification : ISO, CE certificate

Place of Origin : China

MOQ : 1set

Price : $7000-12000

Payment Terms : L/C, T/T, Western Union

Supply Ability : 500 Set/ Year

Delivery Time : 15~30 days

Packaging Details : container

Name : machine room less elevator

Load : 630-1600kg

Speed : 1.0m/s--1.75m/s

Drive Type : AC, VVVF

Machine room type : Machine room lift/Machine room less lift

Machine : Gearless

Voltage : 380V/220V

Type : MRL

Transportation : Sea Delivery

Model : machine room less elevator

Product : machine room less elevator

Contact Now

Wholesale Low Noise Etched Stainless Steel Good Quality Passenger Elevator

1600kg 1.0m/S Low Noise Etched SS Machine Room Less Elevator for Building

Machine-room-less elevators utilize a gearless traction machine located in the hoistway. The use of a counterweight assists the machine in turning the elevator sheave, which moves the cab through the hoistway. Most commonly seen in hotels, apartments, mixed-use buildings and commercial offices, MRL elevators can handle 2 to 25 stops (with a typical capacity of 2,100 to 5,000 lbs.) and feature flexible design. Large capacities (4,000 lbs. and above) can accommodate heavier cab finishes.

machine room-less passenger elevator:

Load Speed Car size

Door opening

size

Shaft size

Maximum

landing

Maximum

lifting height

kg m/s CW CD CH OP OPH HW HD K S
630 1 1100 1650 2500 700 2100 2400 1800 4250 1600 20 60
1.5 4400 1700 24 72
1.75 4500 1700 30 90
800 1 1350 1850 2500 900 2100 2500 1800 4250 1600 20 60
1.5 4400 1700 24 72
1.75 4500 1700 30 90
1000 1 1600 1950 2500 900 2100 2550 1800 4250 1600 20 60
1.5 4400 1700 24 72
1.75 4500 1700 30 90
1350(widecar) 1 1500 1950 2500 1100 2100 2850 2000 4550 1600 20 60
1.5 4600 1700 24 72
1.75 4700 1700 30 90
1350(deepcar) 1 2300 2250 2500 1100 2100 2150 2800 4550 1600 20 60
1.5 4600 1700 24 72
1.75 4700 1700 30 90
1600(widecar) 1 1700 1950 2500 1100 2100 2850 2100 4550 1600 20 60
1.5 4600 1700 24 72
1.75 4700 1700 30 90
1600(deepcar) 1 2400 2250 2500 1200 2100 2250 2900 4550 1600 20 60
1.5 4600 1700 24 72
1.75 4700 1700 30 90





1600kg 1.0m/S Low Noise Etched SS Machine Room Less Elevator for Building1600kg 1.0m/S Low Noise Etched SS Machine Room Less Elevator for Building1600kg 1.0m/S Low Noise Etched SS Machine Room Less Elevator for Building1600kg 1.0m/S Low Noise Etched SS Machine Room Less Elevator for Building



1600kg 1.0m/S Low Noise Etched SS Machine Room Less Elevator for Building

1600kg 1.0m/S Low Noise Etched SS Machine Room Less Elevator for Building


FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
